1. R61540080017A Injector Orifice Plate 31# Basic Information

Title	Common Rail Orifice Plate 31# for R61540080017A fuel Injector	Product Quality
SKU1	G1L32000D009031DZ	China made new
SKU2	G1Z110000000031	China made new
SKU3	L3200000D009031	China made new
SKU5	G1N12950403100	China made new

2. R61540080017A Injector Orifice Plate 31# Common Part Number

• R61540080017A Injector Orifice Plate 31# Application to Car Model Information

Injector Part Number	Car Model	Car Model	OE Number
R61540080017A	CNHTC TRUCK WD615	/	/

3. R61540080017A Injector Orifice Plate 31# Specifications and Dimensions

Injector Orifice Plate’s Size：2cm*2 cm *1 cm

Injector Orifice Plate’s Box Size: 7cm *7 cm *2 cm

Injector Orifice Plate’s Package Size：  8 cm * 8cm

Injector Orifice Plate’s Net Weight：0.015kg

Injector Orifice Plate’s Gross Weight：0.03kg

Injector Orifice Plate’s Quality：China Made Brand New

MOQ：4 Pieces

4. R61540080017A Injector Orifice Plate 31#Customized Service

• R61540080017A Injector Orifice Plate 31# Customized Service Range:

The customization amount of orifice plate 31# must meet the OEM manufacturers customized demands of orifice plate’s lettering, orifice plate’s thickness, orifice plate’s packing box, orifice plate’s anti-rust bag and label etc,.

• R61540080017A Injector Orifice Plate 31# Customized Service Requirements：

▲ Custom lettering of injector orifice plate are not less than 100 pieces.

▲ Custom packing boxes of injector orifice plate are not less than 100 pieces.

▲ The purchase of injector orifice plates are not less than 100 pieces.

▲ When customized products involve the need of specific logo, the OEM manufacturer has to provide trademark authorization and the sample of logo image file.

Once the customized R61540080017A injector orifice plate 31# is sold, it cannot be returned or exchanged if there is no quality problems.











5.  R61540080017A Injector Orifice Plate 31# Thickness Measurement Tool’s Introduction

• Electronic Vernier Caliper
•  Technical Parameters

1. Made of stainless steel.
2. Resolution: 0.01mm/0.001.
3. Can set on zero at any location.

• Electronic Digital Display Micrometer
•  Technical Parameters

1. Range: 0-25mm,25-50mm,50-75mm,75-100mm
2. Resolution: 001mm
3. Power: Voltage 1.5V button battery
4. Working Temperature: 0∽+40℃
5. Storage Temperature: -20∽+70℃
6. Environment Humidity: ≤80%

6.  R61540080017A Injector Orifice Plate 31# Thickness Measurement Methods

• Electronic Vernier Caliper

Notice: When using the electronic vernier caliper, be sure to return on zero port, otherwise there will be a large error in the measurement results!

• Electronic Digital Display Micrometer

7. R61540080017A Injector Orifice Plate 31# Quality Control

（1） R61540080017A Injector Orifice Plate 31# Testing

All R61540080017A injector orifice plate 31# parts are subjected to A-hole flow test, Z-hole flow test, precision test, high temperature test, low temperature test, pressure test, leakage test, durability test, and various working condition tests.

（2） R61540080017A Injector Orifice Plate 31#  Inspection

The factory inspection of R61540080017A injector orifice plate 31# is undergone three inspections – full inspection, random inspection, and batch inspection. Different brands of test benches are used to test R61540080017A injector orifice plate 31# for a total of no less than three times for factory inspection, and R61540080017A injector orifice plate 31# installation testing environment are progressed in dust-free workshop.

8. R61540080017A Injector Orifice Plate 31# Warranty Instructions

（1）. R61540080017A Injector Orifice Plate 31# Warranty Conditions and Instructions

▲  It is necessary to provide the pictures, videos of R61540080017A injector orifice plate 31# when the injector orifice plate is abnormal during use or the test report of R61540080017A injector orifice plate 31# inspection equipment as evidence to feedback to the salesman.

▲  Abnormal conditions are properly explained such as：1.Black smoke, 2. Engine shake, 3. Difficulty starting the engine, 4. Engine noise, 5. Oil leakage etc.

▲  The above conditions may also be affected by incorrect installation of the fuel injector. If it is confirmed that it is product problem after being tested by our company,  the injector orifice plate is within the scope of warranty.





（2）. R61540080017A Injector Orifice Plate 31# Warranty Coverage

▲  After customer receives the R61540080017A injector orifice plate 31# within 15 days , customer can choose to replace it if there is a performance failure and the product has no appearance damage;

▲  If the R61540080017A injector orifice plate 31# has performance problems during the warranty period (3 months), and it is confirmed to be product’s problems after being tested, you can contact our salesmen to replace the same model or a reworked product with the same performance for free;

If the injector orifice plate is confirmed to be fault-free, it can only be repaired and it will be returned as original way.

（3）. R61540080017A Injector Orifice Plate 31# Out of Warranty Coverage

▲ The R61540080017A injector orifice plate 31# is artificially damaged due to assembly errors during the process of assembling.

▲  The warranty period has expired.

▲  R61540080017A injector orifice plate 31# failure caused by high temperature, high pressure, humidity, rain and snow, saline-alkali land, earthquake, and used in abnormal environment.

▲ R61540080017A injector orifice plate 31# damage caused by man-made reasons (throwing, strong magnetic field magnetization, set fire).

▲  R61540080017A injector orifice plate 31# failure or injector damage caused by non-injector orifice plate’s design, technology, manufacturing, quality and other issues.

▲ I R61540080017A Injector orifice plate 31# failure due to system pressure exceeding system approved pressure.

▲ R61540080017A injector orifice plate 31# failure caused by impurities (water, lead, aluminum powder, iron powder, sulfide) in the system fuel exceeding the standard requirements.

▲ R61540080017A injector orifice plate 31# failure caused by not installing according to the tightening torque specified in the vehicle engine maintenance manual (the tightening torque is too large or too small).

▲ R61540080017A injector orifice plate 31# failure caused by not following the installation angle specified in the vehicle engine maintenance manual.

▲ R61540080017A injector orifice plate 31# failure caused by not following the cleaning requirements specified in the vehicle engine maintenance manual.

▲ R61540080017A injector orifice plate 31# failure caused by failure to replace consumable parts as specified in the vehicle engine maintenance manual.

9. R61540080017A Injector Orifice Plate 31# Installation Steps

For further information of orifice plate 31# installation steps, please check on “31# Orifice Plate for R61540080017A Injector Technical Data” 2.4. R61540080017A Injector Orifice Plate 31# Installation Steps







10.  R61540080017A Injector Orifice Plate 31# Purchase Payment Methods

Payment methods：T/T, PayPal, Alipay, WeChat

11.  R61540080017A Injector Orifice Plate 31# Shipping Ways

Destination in China areas: SF Express, Debon Express, the corresponding logistics company can be provided according to customer requirements in special cases.

Destinations out of China’s areas： DHL, UPS, FedEx, TNT air, ocean or other shipping methods required by customers.

12.  R61540080017A Injector Orifice Plate 31#Packing

Domestic express packaging：   Wrapped with Transparent tape	International express packaging： Wrapped with yellow tape after wrapping with black protective film	Pallet Shipping：Use pallet that meet export requirements, and use white wrapping protective film to wrap and bind with cable ties
